PZT Material Selection Guide

FUJI CERAMICS always has dozens of types of piezoelectric ceramic materials.

Our seven (7) types of materials are presented here with properties similar to those commonly used internationally.

< C-21 >
Equivalent to NavyⅠ/PZT-4
For high power driving

< C-204 >
Equivalent to NavyⅠ/PZT-4
Middle Qm / High k33 / High d33

< C-64 >
Equivalent to NavyⅡ / PZT-5A
High Tc

< C-602 >
Equivalent to NavyⅡ / PZT-5A
High Tc / Stable temp. coefficient

< C-203 >
Equivalent to NavyⅢ / PZT-8
High d33 / High Qm / High Tc

< C-62 >
Equivalent to NavyⅤ / PZT-5J
High k33 / High d33

< C-82 >
Equivalent to NavyⅥ / PZT-5H
Highε33T / High d33 / Low Qm



Please see the chart below or download PDF for details.

If you have any requests, please contact us from the inquiry form.
